The complete toolbox for three-phase testing and measuring the turns ratio, excitation current, and phase shift of power, distribution and current transformers.



Features:

• Ratio range  45000 : 1
• Adjustable excitation test voltage: 1V to 250V
• Excitation current range: 1uA to 1A
• Phase shift accuracy: ±0.05º
• Automatic detection of 64 vector groups
• Tap changer continuity test
• Built-in tap changer control unit
• Providing user safety with an emergency stop button
• Battery and main line operated with fast charge
• USB connectivity with PC software
• WIFI connectivity with user-friendly mobile app.
• Portable, heavy-duty, and light weight case
• Extremely reliable and easy to use

Applications:

• High power transformer manufacturers
• Repair and maintenance of electrical power plant companies
• Electrical power plant EPC companies
• Electrical power labs
• Big factories e.g. Steel, petrochemicals, refineries, and...
